Why Dual Power Systems Use Transfer Instead of Parallel Operation

Before answering this question, let's first consider another one:

What are the conditions for transformers to operate in parallel?

1. Equal rated primary and secondary voltages The voltage ratios of transformers operating in parallel must be identical. If they differ, circulating currents will occur in the secondary circuit. The winding with higher voltage will feed the lower one, leading to overheating or even damage.

2. Equal impedance voltage Load sharing among parallel transformers is inversely proportional to their impedance. If impedance voltages differ significantly, the transformer with lower impedance may become overloaded. Therefore, matching impedance is essential.

3. Same vector group (connection group) The phase sequence and phase displacement must be identical. Any phase difference will result in circulating currents, significantly increasing the risk of winding damage.

4. Capacity ratio within 3:1 The capacity ratio between transformers should not exceed 3:1. Ideally, capacities should be similar. Large differences can lead to operational challenges and increased circulating currents, especially overloading smaller units.

Why discuss transformer parallel operation? Because these same principles explain why dual power supply systems typically do NOT operate simultaneously.

Now, back to the main topic:

A dual power supply system refers to two independent power sources feeding the same load or system. By definition, achieving true parallel operation is extremely difficult in practice, especially in terms of matching voltage, impedance, and phase conditions.

Here’s why dual power systems are generally not designed for simultaneous supply:

1. Purpose: Reliability over Capacity

The primary goal of a dual power supply system is to enhance reliability through two independent sources. It is NOT intended to increase capacity or provide economic load sharing like parallel systems.

That’s why mechanical or electrical interlocking is typically implemented—to prevent simultaneous connection.

2. Avoiding Phase Differences

If the two sources are not perfectly synchronized, phase differences can cause unbalanced currents, leading to equipment damage or system failure.

Achieving synchronization requires specialized equipment and precise control.

3. Preventing Circulating Currents

Simultaneous supply can create circulating currents between the two sources. These currents may lead to:

• Overloading (especially with low short-circuit impedance)

• Protection system malfunctions

• System instability and overvoltage risks

4. Simpler Logic, Lower Cost

Operating with a single active source simplifies control logic and reduces system complexity. The system only needs to monitor the main source and switch to the backup when necessary.

This makes single-source operation more economical and efficient.

Conclusion

While theoretically possible under strict conditions, simultaneous power supply in dual-source systems is rarely implemented in practice.

Instead, the industry standard is “one active source + one standby source”, ensuring maximum reliability, safety, and cost-effectiveness.

If you're designing or selecting an ATS system, understanding this principle is critical to making the right decision.
