SKS
AISIKAI
IEC60947-6-1
| Quantity: | |
|---|---|
Advantages and Feature
We use composite moving contacts. The operating mechanisms have energy-storage springsand instant release acceleration mechanisms, realizing instantly making and breaking. Swit-ches have clear indication of ON/OFF and can realize reliable isolation between the powerand the load
The shell is made of unsaturated polyester fiber, which is highly resistant to fire, pressure andtemperature.
High reliability: accurate, flexible and smooth in transfer process, service life over 10000 times
Beautiful appearance, small volume and light weight
In-cabinet operation mechanism and out-of-cabinet operation mechanism are available uponrequest
Technical Data
Frame rating current(Inm) | 100A | 160A | 250A | 630A | 1600A | 3200A | |||||||
Rated current (In) | 100 | 125 | 160 | 250 | 400 | 630 | 800 | 1000 | 1250 | 1600 | 2000 | 2500 | 3200 |
Thermal current rating (Ith) | 10,16,20,25, | 63,80,100, | 125,140,160, | 160,180,200, | 800,1000,1250, | 2000,2500,3200A | |||||||
Rated insulation voltage of copper bar (Ui) | 1000V | ||||||||||||
Rated impulse withstand voltage (Uimp) | 12KV | ||||||||||||
Rated operating voltage of copper bar (Ue) | AC400V/AC690V | ||||||||||||
Rated operating current of copper bar (Ie) | 10,16,20,25,32,40,50,63,80,100,125,140,150,160,180,200,225, | 800,100,012,501,600,000,000,000,000 | |||||||||||
Rated limt short-circuit current | 17KA | 40KA | 67.2KA | 105KA | |||||||||
Rated limt short-circuit current(Iq) | 100KA | 100KA | 100KA | 120KA | 120KA | 120KA | |||||||
50KA | 50KA | 50KA | 65KA | 65KA | 65KA | ||||||||
Start | 40W | 325W | 355W | 400W | 440W | 600W | |||||||
Normal | 18W | 62W | 74W | 90W | 98W | 120W | |||||||
Net weight(kg)4 poles | 3.5 | 5.3 | 5.5 | 7 | 17 | 17.5 | 37 | 44 | 98 | ||||
